CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989

Name: CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989
Brand: PIPE HOUSE
Price: 3385 INR
Availability: InStock

Price 3385 INR/ Meter

Get a Price/Quote

MOQ : 100 Meters

CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989 Specification

Feature
Leak-proof, Robust construction, Corrosion Resistant

Thickness
6mm (nominal)

Surface Finish
Annealing

Tolerance
1mm

End Protector
With or without cast iron ring

Size
As per IS:3989

Surface Treatment
Bitumen Coated

Product Type
Cast Iron Spun Pipes

Material
Cast Iron

Type
Casted

Shape
Round

Standard
IS:3989

Alloy or Not
Non-Alloy

Technique
Spun Cast

Diameter
100mm to 150mm

Length
2.5m to 3m

Tensile Strength
150 N/mm (min)

Hardness
210-230 HB

Color
Black

CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989 Trade Information

Minimum Order Quantity
100 Meters

Supply Ability
1000 Meters Per Month

Delivery Time
15 Days

Main Domestic Market
All India

About CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989

Ever since the establishment of our company in the year 2006, we are regarded as a leading manufacturer and supplier of a broad range of Centrifugal Fittings. The offered fittings are are used in several industrial uses. Made out of top grade raw material with the help of advanced technology and machinery, these fittings are made available in varied lengths, widths and other specifications to meet varied need of clients. Apart from this, our Centrifugal Fittings can be availed by clients at market leading prices within promised time-frame.

Product details

Diameter	75 to 200 mm
Head Shape	Round
Country of Origin	Made in India
Usage/Application	Plumbing Pipe
Type of Coupling	Half
Size	1 inch
Material	cast iron
End Connection Type	Socketweld

Superior Quality for Critical Applications

Designed to meet the stringent requirements of IS:3989, these cast iron fittings are perfect for the ventilation, drainage, and conveyance of rainwater in various soil systems. The robust construction allows for use in both residential and commercial infrastructure, enhancing the reliability of plumbing and drainage networks.

Outstanding Performance and Durability

Manufactured using spun casting techniques, these fittings offer superior tensile strength (minimum 150 N/mm) and hardness (210-230 HB), ensuring long-term performance and resistance to corrosion. The bitumen-coated surface and annealing process provide additional protection and longevity, even in challenging environments.

FAQs of CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989:

Q: How are CAST IRON SOIL WEST VENTILATING RAIN WATER PIPE FITTINGS IS:3989 typically used?

A: These fittings are primarily used in soil systems for efficient ventilation, drainage, and the conveyance of rainwater. Suitable for soil, waste, vent, and rainwater applications, they enhance the durability and leak-proof performance of building drainage networks.

Q: What connection and joint types are compatible with these fittings?

A: These fittings are compatible with socketed, flanged, or spigot connections and can be assembled using either rubber ring or lead caulked joints as per site requirements.

Q: When should I choose cast iron fittings marked with IS:3989 standard?

A: Choose IS:3989-marked cast iron fittings when you require guaranteed quality, robust construction, and compliance with Indian standards for drainage and rainwater conveyance systems in both new constructions and renovations.

Q: Where are these cast iron soil and ventilating fittings commonly installed?

A: These fittings are commonly installed in residential, commercial, and industrial buildings across India for soil waste, venting, and rainwater systems wherever strong, corrosion-resistant drainage solutions are needed.

Q: What is the manufacturing process for these pipe fittings?

A: Manufactured by spun casting from non-alloy cast iron, these fittings undergo an annealing process to enhance strength. Quality is assured with a bitumen coating for corrosion resistance and each fitting is clearly marked with IS:3989, manufacturers name, and size.

Q: How do these fittings benefit my plumbing system?

A: They provide a leak-proof, robust solution with excellent resistance to corrosion and pressure up to 0.5 MPa, making your drainage and ventilation reliable and long-lasting, reducing the need for frequent maintenance.
